High-Speed Rack Pinion Wood Door Cutting Machine 3000mm Max Cutting Length

Very large door leaves punish a saw that relies on light positioning systems. The DXW Series high-speed wood door cutting machine drives its axes with a high-precision ground gear rack and screw transmission, so long travel does not cost accuracy. With a maximum processing length of 3000 mm and a maximum processing width of 1100 mm, it handles full-size door leaves and oversized panels, while the axes move at up to 60 m/min to keep the cycle short.

• Ground Rack and Pinion: Precision-ground gear racks transfer force evenly along the full travel, so the head stays accurate from the shortest to the longest door.
• 3000 mm Cutting Length: The machine processes door lengths from 1800 mm up to 3000 mm, covering standard and oversized interior doors.
• 1100 mm Working Width: A wide working envelope accepts door widths up to 1100 mm without repositioning the workpiece.
• 60 m/min Travel Speed: High axis speed keeps idle time low even when covering the full length of a large door leaf.
• Rigid Guide Structure: Heavy guide rails and screw drive resist deflection, protecting accuracy when cutting dense or thick panels.
• Smooth Acceleration: Servo control ramps motion smoothly, reducing shock on the rack and pinion and extending service life.

This rack pinion wood door cutting machine is built for manufacturers whose product range includes long or oversized door leaves that push the limits of ordinary saws.

• Oversized and long door leaf production
• Double doors and wide interior doors
• Thick solid wood and composite doors
• Factories cutting a wide size range on one machine
• High-volume lines needing fast long-axis travel

What is the maximum door size it can handle?

The machine cuts door leaves from 1800 mm up to 3000 mm in length and 400 mm up to 1100 mm in width, with a thickness range of 30-60 mm.

Why use a rack and pinion drive?

A ground gear rack distributes drive force along the entire travel, so the saw head stays accurate at any position and resists deflection on long, heavy cuts.

Does the high travel speed reduce cut quality?

No. The axes settle before the saws engage and the cutting speed is regulated at up to 20 m/min, so rapid positioning and a clean cut are achieved together.

Can it cut thick panels?

Yes. The rigid guide structure and screw-assisted transmission allow stable cutting of door thicknesses up to 60 mm, including denser composite cores.

The rack pinion wood door cutting machine is shipped in a reinforced fumigated wooden case with the gear racks, guide rails and saw groups braced to prevent movement. Drives and controllers are moisture-sealed. Installation documentation, spare blades and remote or on-site commissioning support are provided.
